Eventide’s BD600 profanity delay has been updated to support WheatNet-IP, Wheatstone’s audio-over-IP standard. The unit provides up to an impressive 80s of delay and is the culmination of thirty years of designing and manufacturing highly reliable broadcast delays.

[heading type=4]THE NEW STANDARD FOR PROTECTION[/heading]
The BD600W offers an unprecedented 80 seconds of the highest quality revenue and license-protecting delay – twice as much as other delays. You have the flexibility to customize the delay buffer length from four seconds to the full 80 seconds. Dump can be customized in 1/2 second increments up to 10 seconds. Each time the DUMP button is pressed, only one segment is deleted. For example, if a unit is set to the full 80 seconds of delay buffer, and is set up to provide 8-second dumps, you will have ten separate dump segments. Pushing the DUMP button the first time cuts out one 8-second segment. You still have 72 seconds of delay protection. If this is followed by more trash-talk, push the DUMP button again and you still have over a minute of delay protection. The “sneeze” button momentarily “edits” audio entering the delay, allowing the host to sneeze, cough, or make a short comment without being heard on air – and without dead air. Your station cannot afford to work without a net. With the BD600, you will never worry about running out of delay memory.

BD600W-front



[heading type=4]THE NEW STANDARD FOR FEATURES[/heading]
If 80 seconds of delay protection were not enough, the BD600 has a secondary backup called PANIC. This plays a .WAV file stored on a compact flash card. While the file – a jingle, ID or other message – is played, delay is being built up in real time, allowing programming to continue in safety as soon as the jingle is over. This can also be used for painless entry into delay.

The unit shows not only an exact digital readout of delay time, but also has a “quick read” bar graph which instantly confirms “you’re safe” at a glance. The BD600 is an 80-second stereo delay unit featuring analog XLR-type inputs and outputs, as well as AES/EBU digital audio inputs and outputs. All front panel switches (except “configure”) can be remoted, as can the status indicators. Both RS-232 in and out are included; four configurable control inputs and two configurable relay-isolated control outputs are provided via an easy-to-wire Euroblock barrier strip.

BD600W-rear



[heading type=4]EXPANDED REMOTE CAPABILITY[/heading]
The Optional BD600 Extended Remote is perfect for more sophisticated automated broadcast chains. 16 bipolar opto-isolated inputs may be configured to drive BD600 functions and general-purpose delay inputs. 16 open-collector outputs may be configured to output BD600 status indicators or to pass through delayed versions of the inputs. An RS-232 output provides a delayed version of the input, useful for driving a time display or for other control purposes.
